The iConEx XY900F Series is a rugged line of industrial Human-Machine Interface (HMI) touch screens, engineered exclusively for reliable operation in non-hazardous but environmentally harsh industrial settings. Unlike iConEx’s explosion-proof HMI lines (e.g., XY800, XY900), its defining strength lies in overcoming extreme temperatures and intense ambient light—delivering exceptional visibility and performance in outdoor installations, unheated warehouses, and harsh indoor environments where standard HMIs falter.
It combines a high-performance 32-bit RISC CPU (running a streamlined Linux OS) with a vibrant TFT LCD, striking a balance of processing power, environmental resilience, and sunlight readability. It is ideal for automation tasks in industries like renewable energy, construction machinery, logistics, and outdoor process control.
Core Design Philosophy: Mastering Environmental Extremes
The XY900F Series is built on a singular principle: maintain full functionality and display clarity amid thermal stress and optical interference. Unlike explosion-proof HMIs focused on containing hazardous atmospheres, this model prioritizes defeating two key industrial challenges:
Extreme temperature fluctuations (from sub-zero cold to scorching heat).
Glare and washed-out displays caused by intense ambient light.
Its wide-temperature components and high-luminance LED backlight ensure the interface remains responsive and content sharp—no external protective enclosures, heaters, or sun hoods required.
Product Features & Characteristics
Sunlight-Readable High-Brightness Display: Equipped with TFT LCDs (standard: ≥300 cd/m²; high-brightness option: ≥600 cd/m²) with optional optical bonding. This reduces glare and boosts contrast, guaranteeing clear visibility of process graphics and data even in direct sunlight—a critical advantage for outdoor applications.
Extended Temperature Resilience: Offers three temperature grades to match diverse environments:
Standard: 0°C ~ +55°C
Low-Temp: -20°C ~ +60°C
Wide-Temp: -40°C ~ +60°C
Ensures reliable startup and operation in cold storage, winter outdoor settings, and hot industrial zones.
Robust Processing & Connectivity: Powered by a 400MHz/800MHz 32-bit RISC CPU with 128MB Flash and 64MB DDR2 DRAM. Supports isolated serial ports (RS-232/485/422), Ethernet, and USB hosts for seamless integration with major PLCs and controllers.
Advanced Customization: Uses XYFD2000 configuration software with C-like macro scripting, enabling complex control logic, custom data handling, and tailored user interfaces directly on the HMI.
Industrial-Grade Durability: Features a metal or heavy-duty plastic enclosure with front-panel IP65 (or higher) protection against dust and water jets. Resistive touch technology ensures reliable operation with gloves or light moisture.
Key Specifications
Parameter/Category
Specification Details
Model Series iConEx XY900F (e.g., XY900F_7HMI, XY900F_10HMI, XY900F_15HMI)
Display Type TFT LCD, Resistive Touch (Single-point)
Available Sizes 7", 10.4", 12.1", 15"
Resolution 800x480 (7"), 800x600 (10.4"), 1024x768 (15")
Brightness Standard: ≥300 cd/m²; High-Brightness Option: ≥600 cd/m²
CPU 32-bit RISC ARM (400MHz or 800MHz)
Memory 128MB Flash, 64MB DDR2 DRAM
Operating System Streamlined Linux Kernel
Communication Ports Isolated RS232/RS485/RS422, Ethernet (10/100M), USB Host/Device
Input Power DC 24V (typical)
Power Consumption ~4W (7") to ~15W (15") (Model dependent)
Protection Rating (Front) IP65 (or higher, model dependent)
Hazardous Area Certification Not Applicable (Designed for non-hazardous areas)
Operating Temperature Standard: 0°C ~ +55°C; Low-Temp: -20°C ~ +60°C; Wide-Temp: -40°C ~ +60°C
Touch Technology Resistive (Glove & stylus operable)
Installation Panel Mount (Front mounting)
Applications
The XY900F Series excels in environmentally demanding, non-hazardous scenarios—distinct from the explosion-prone settings of iConEx’s other HMI lines:
Renewable Energy Plants: Monitoring solar PV inverters, wind turbine pitch systems, and battery storage (BESS) in outdoor fields.
Construction & Agricultural Machinery: Serving as operator interfaces on excavators, cranes, and harvesters (exposed to dust, vibration, and temperature swings).
Outdoor Logistics: Controlling automated stacking cranes (ASCs) in container yards, outdoor conveyors, and parcel sorting hubs.
Cold-Environment Food Processing: Operating in cold storage rooms, refrigerated processing areas, and wash-down zones (with appropriate IP ratings).
Wastewater Treatment: Monitoring outdoor pumps, blowers, and filters exposed to rain, humidity, and temperature extremes.
Product Advantages
The XY900F Series’ greatest strength is its specialized focus on environmental resilience for non-hazardous settings:
Unmatched Visibility: High-brightness and optical bonding eliminate washed-out displays in sunlight, avoiding costly supplemental sun hoods.
Thermal Versatility: Wide-temperature models remove the need for external heaters or air conditioners, simplifying installation and reducing energy use.
Cost-Effective Durability: IP65 protection and resistive touch deliver industrial ruggedness without the premium of explosion-proof certifications—ideal for budget-conscious non-hazardous applications.
Seamless Integration: Compatibility with major PLCs and XYFD2000 software ensures it fits into existing automation systems with minimal reconfiguration.
FAQs
1. What is the significance of the high-brightness display (e.g., ≥600 cd/m²) in the XY900F?
A high-brightness display is critical for overcoming ambient light interference in industrial settings:
Standard HMIs (250–350 cd/m²) appear washed out under direct sunlight, glass-walled warehouses, or skylighted workshops—making process data unreadable.
The XY900F’s ≥600 cd/m² backlight overpower s ambient light, ensuring clear visibility of graphics, trends, and alarms at a glance.
This enhances safety and efficiency by eliminating operator errors from misreading screens, even in unshaded outdoor or brightly lit indoor locations.
2. How does the wide operating temperature range (-40°C to +60°C) benefit the XY900F’s applications?
The extended temperature range expands the HMI’s usability and reliability in extreme environments:
Cold Resilience: In sub-zero settings (e.g., winter outdoor machinery, cold storage), wide-temperature components and optional heaters prevent LCD freezing and sluggish performance—ensuring reliable cold starts.
Heat Resistance: In hot zones (e.g., solar farms, machinery cabins), robust thermal design avoids overheating, premature component failure, or automatic shutdowns.
Cost Savings: Eliminates the need for external thermal management (heaters/AC units) and protective enclosures, simplifying installation and reducing long-term maintenance.
3. Why choose a resistive touch screen for the XY900F over a capacitive one?
Resistive touch is a pragmatic choice for the XY900F’s industrial use cases:
Glove Compatibility: Operates reliably with thick work gloves (standard for construction, logistics, and food processing)—capacitive screens require bare fingers or special styluses.
Contaminant Resistance: Responds to pressure, so dust, water droplets, or grease on the surface do not cause false touches—critical for dirty or wet industrial environments.
Durability: Glass-and-film construction resists scratches and abrasions from tools or rough handling, outperforming many capacitive screens in rugged settings.
