5 Port Unmanaged Industrial Switch Hirschmann RS2-5TX, 24VDC DIN Rail Mount

　　The Hirschmann RS2-5TX stands as a paradigm of simplicity and robustness in the realm of industrial networking.This device is explicitly engineered as a 5 Port Industrial Switch that operates on an unmanaged basis,providing a plug-and-play solution for creating resilient and dependable network segments in harsh environments.Designed for applications where fundamental connectivity and data throughput are paramount,it forgoes complex configuration features in favor of unwavering reliability and ease of installation.Its hardened design ensures stable communication for a wide array of automated systems,making it an indispensable component for basic yet critical network infrastructure within factory automation,process control,and other industrial settings.

　　1.Product Core:Technical Specifications and Functional Design

　　The Hirschmann RS2-5TX is defined by a set of technical parameters that underscore its purpose as a durable and efficient workhorse.It is an Unmanaged Industrial Switch,meaning it requires no user configuration to operate,automatically handling network traffic using store-and-forward technology.

　　Technical Specifications Overview:

　　The switch features five RJ45 ports,each supporting 10/100Base-TX standards,which means they auto-negotiate speed and automatically configure themselves for cross-over or straight-through cabling.This eliminates the need for special cables or manual settings.The unit is powered by a 24 V DC input with a wide tolerance range from-25%to+30%,ensuring stable operation despite common voltage fluctuations in industrial power supplies.Its compact housing measures 40 x 145 x 80 mm(width x height x depth)and is designed for efficient mounting on a standard 35 mm DIN rail,a staple in industrial control cabinets.Weighing 520 grams,it is both sturdy and lightweight.

　　In-Depth Functional Analysis:

　　The core operation of this 5 Port Industrial Switch is based on the store-and-forward switching mode.In this method,each data packet is fully received and checked for errors before being forwarded to its destination port.This process enhances network integrity by preventing corrupted data packets from propagating through the system.The integrated LEDs for power,link status,data activity,and faults provide immediate visual diagnostics,allowing for quick assessment of the network's health without the need for sophisticated software.

　　2.Design Philosophy:Ruggedness for Industrial Environments

　　The physical and electrical design of the RS2-5TX is tailored to survive and operate reliably in conditions that would challenge standard commercial networking equipment.

　　Environmental Robustness and EMC Compliance:

　　This Unmanaged Industrial Switch is built to operate in temperatures from 0 to 60°C and can withstand storage and transport temperatures from-25 to 70°C.It boasts an impressive Mean Time Between Failures(MTBF)of 116.3 years,as calculated per MIL-HDBK-217F standards,highlighting its exceptional predicted reliability.A key aspect of its design is its comprehensive ElectroMagnetic Compatibility(EMC)protection.It is fortified against electrostatic discharge(4 kV contact,8 kV air),electromagnetic fields(10 V/m),electrical fast transients(2 kV on power lines),and surge voltages(1 kV line-to-ground).This extensive protection ensures continuous operation in electrically noisy industrial environments.The housing provides an IP20 protection rating,safeguarding it against the ingress of solid objects larger than 12.5 millimeters,making it suitable for most control panel interiors.

　　Installation and Power Supply Redundancy:

　　The DIN rail mounting facilitates quick and secure installation in control panels.A significant feature for mission-critical applications is the integrated 24 V DC power redundancy.This design allows the switch to maintain operation even if one power supply fails,a crucial feature for enhancing overall system uptime.

　　3.Application Areas and Industry Solutions

　　The plug-and-play nature and rugged build of the Hirschmann RS2-5TX make it ideal for a diverse range of industrial applications.

　　Factory Automation Cells:It is perfectly suited for creating small,localized networks within a single machine or an automated work cell,connecting devices like PLCs,HMIs,motor drives,and sensors.

　　Process Control and Monitoring:In systems for water treatment,chemical processing,or other industrial processes,it provides reliable connectivity for instruments and controllers that do not require the advanced features of a managed switch.

　　Transportation and Infrastructure:Its robustness makes it a candidate for ancillary systems in transportation,such as within control panels for baggage handling,station information displays,or tunnel ventilation control,where environmental conditions can be demanding.

　　4.Operational Advantages and Economic Benefits

　　Choosing the Hirschmann RS2-5TX brings several tangible advantages that contribute to lower total cost of ownership and enhanced operational stability.

　　Simplified Deployment and Maintenance:As an Unmanaged Industrial Switch,it can be integrated into a network straight out of the box.This eliminates configuration time and the need for specialized networking knowledge,reducing both installation and training costs.

　　Enhanced System Reliability:The combination of a high MTBF,wide operating temperature range,and robust EMC immunity translates into minimal network downtime.This reliability is essential for maintaining continuous production and avoiding the high costs associated with unplanned stoppages.

　　Cost-Effectiveness:For applications that require basic,reliable connectivity without the need for VLANs,traffic prioritization,or network management protocols,the RS2-5TX provides a high-performance,cost-efficient solution without paying for unused advanced features.

　　Expanded Perspective:The Strategic Role of Unmanaged Switches in Industrial Networks

　　Understanding where an unmanaged switch fits within the broader industrial networking hierarchy is crucial for making an informed component selection.

　　1.The Network Switch Hierarchy:Unmanaged vs.Managed

　　The choice between an unmanaged and a managed switch is a fundamental decision in network design.

　　Unmanaged Switches(Like the RS2-5TX):These devices are"plug-and-play."They provide basic connectivity,allowing devices to communicate with each other on a local network segment.They do not support configuration interfaces,VLANs,or Simple Network Management Protocol(SNMP).Their primary advantage is simplicity,low cost,and reliability for foundational connectivity.

　　Managed Switches:These offer full management capabilities,including configuration of individual ports,traffic prioritization(Quality of Service),creation of VLANs to segment network traffic,and monitoring via SNMP.They are essential for complex,mission-critical networks where control,security,and visibility are required.

　　Selection Insight:The Hirschmann RS2-5TX Unmanaged Industrial Switch is the optimal choice for applications requiring a simple,reliable,and cost-effective way to connect a small group of devices in a localized area.It is the default for non-critical,flat networks where advanced features are unnecessary.A managed switch is required for larger,segmented networks,for creating redundant topologies(like rings),or when network monitoring and security are priorities.

　　2.Critical Considerations for System Implementation

　　Implementing a robust network with an unmanaged switch like the RS2-5TX still requires careful planning.

　　Network Topology and Cascading Limits:While the RS2-5TX can be used in star,line,or tree topologies,it's important to remember that cascading too many unmanaged switches can lead to performance issues like broadcast storms in larger networks.For extensive networks,a backbone of managed switches is recommended.

　　Physical Environment and Installation:Even with its robust design,the switch should be installed within a control cabinet for maximum protection,especially in environments with excessive dust,moisture,or corrosive agents that exceed its IP20 rating.

　　Product Lifecycle Status:It is important to note that the RS2-5TX has been declared obsolete.For new installations,it is recommended to consult with Hirschmann or a certified distributor to identify the current direct replacement model to ensure long-term support and availability.

　　Frequently Asked Questions(FAQs)

　　What is the primary operational difference between an unmanaged switch and a network hub?

　　While both devices connect multiple network devices,an unmanaged switch like the RS2-5TX is significantly more intelligent.A hub broadcasts all incoming data to every port,leading to collisions and reduced performance.A switch learns the MAC addresses of connected devices and intelligently forwards data only to the specific port of the intended recipient.This greatly improves network efficiency and data security within the local segment.

　　Is the Hirschmann RS2-5TX still a recommended product for new designs?

　　No,the RS2-5TX has reached its end-of-life and is considered obsolete.While it may be available through certain distributors,it is not recommended for new projects.It is crucial to seek its official successor,which likely offers similar or enhanced functionality in the same form factor,to ensure future-proofing and product support.

　　How does the wide operating temperature range benefit an industrial application?

　　Industrial environments,particularly control cabinets located on factory floors,can experience significant temperature variations.The RS2-5TX's ability to function reliably from 0 to 60°C ensures consistent network operation without the need for additional cooling systems,which adds complexity and cost.This ruggedness is a key differentiator from commercial-grade switches.

　　Can this 5-port switch be used to build larger networks?

　　Yes,the ports on the RS2-5TX support auto-negotiation and auto-crossing,allowing you to connect it to other switches to expand the network.However,for building large,complex networks,a foundation of managed switches is generally advised to manage traffic,prevent loops,and maintain network stability.The RS2-5TX is ideal as an endpoint switch for a small cluster of devices.
