The HIKROBOT MV-LBSS-27-27-W is a high-uniformity industrial light led designed for precision machine vision applications. This led industrial lighting solution utilizes a compact form factor and a white LED array to deliver stable and consistent illumination, crucial for automated inspection tasks.
The MV-LBSS-27-27-W features a 27 mm x 27 mm emitting area and operates with a color temperature of 6000-7000K, providing clear and detailed imagery. Its electrical characteristics include a power consumption of 1.6 W and an SMR-03V-B interface type. Structurally, it measures 37 mm x 37 mm x 15 mm with a power supply cable length of 500 mm, making it suitable for integration into space-constrained automated systems. The operating temperature range is 0-40°C, with storage temperatures from -20-60°C, and it can function within 20-85% RH humidity without condensation. A standard diffusion plate is included, which is instrumental in minimizing glare and hotspots, thereby enhancing image contrast and simplifying algorithm development for tasks like edge detection.
This specific model is well-suited for applications such as printed circuit board (PCB) character verification, small component gauging, and surface inspection of medical devices. Its diffuse flat panel design ensures uniform light distribution, which is essential for applications demanding shadow-free and glare-free imaging. While ideal for inspecting flat, reflective, or small-scale objects, it may not be the optimal choice for long-distance illumination tasks, where bar or spot lights might be more appropriate.
The HIKROBOT MV-LBSS-27-27-W is part of a broader series of industrial lighting solutions from HIKROBOT, which includes various other models designed to meet diverse application needs. These include, but are not limited to, models such as the MV-LBSS-48-28-W, MV-LBSS-50-50-W, MV-LBSS-70-70-W, MV-LBSS-100-100-W, MV-LBSS-120-120-W, MV-LBSS-150-100-W, MV-LBSS-150-100-R, MV-LBSS-180-150-W, MV-LBSS-200-160-W, MV-LBSS-200-200-W, MV-LBSS-250-125-W, MV-LBSS-250-150-R, MV-LBES-180-180-W, MV-LBES-180-180-B, MV-LBES-240-240-W, MV-LBES-300-300-W, MV-LBSS-400-200-W, MV-LBES-450-320-W, MV-LBES-620-620-W, MV-LBFS-100-100-W, MV-LBFS-200-150-W, MV-LBFS-400-300-W, MV-LBFH-50-50-W, MV-LBFH-100-100-W, MV-LBFH-200-150-W, MV-LBFH-300-200-W, MV-LBFH-400-300-W, MV-LBPS-27-27-W, MV-LBPS-50-50-W, MV-LBPS-50-50-B, MV-LBPS-100-50-B, MV-LBPS-100-100-W, MV-LBPS-120-120-W, MV-LBPS-120-120-R, MV-LBPS-150-100-W, and MV-LBPS-250-200-W. These models collectively offer a wide range of specifications, including different sizes, power outputs, and form factors like flat lights with holes (e.g., MV-LBES-H series) and dome lights (e.g., MV-LGSS series), catering to various machine vision illumination requirements.
The MV-LBSS-27-27-W is particularly effective in industrial scenes such as automotive assembly lines and food packaging processes. In these environments, its uniform illumination capabilities enhance the precision of robotic guidance systems, ensure accurate quality control of components, and improve the efficiency of automated visual inspection, thereby contributing to increased throughput and reduced error rates. The consistent light output minimizes variability in image capture, which is critical for maintaining high levels of performance in continuous production cycles.
Frequently Asked Questions (FAQ)
Q: What is the warranty period for the HIKROBOT MV-LBSS-27-27-W?
A: Standard warranty terms are provided through authorized regional distributors. For detailed warranty information specific to your region and bulk purchase agreements, please consult with our sales representatives.
Q: How can I verify if the HIKROBOT MV-LBSS-27-27-W I received is a genuine, factory-sealed product?
A: Genuine products are typically supplied with tamper-evident seals and unique serial numbers. We recommend purchasing directly from authorized regional distributors or authorized resellers to ensure authenticity and proper traceability. For large project procurement, a multi-point inspection protocol can be arranged.
Q: Are there specific calibration requirements for the MV-LBSS-27-27-W to ensure optimal performance in my application?
A: While the light is designed for plug-and-play operation, optimal performance can be achieved through proper setup and integration. Our technical support department can provide guidance on recommended operating distances and optimal camera settings based on your specific application details, ensuring the best possible image acquisition.
Q: What is the typical lifespan of the LEDs in the MV-LBSS-27-27-W under continuous operation?
A: The LEDs are rated for tens of thousands of hours of operation under specified environmental conditions. For applications operating near the upper limit of the working temperature range (40°C), or those requiring extended duty cycles, actively managing ambient temperature or consulting with our engineers about derating factors is advised to maximize longevity.
Q: Can the MV-LBSS-27-27-W be used in extremely dusty or humid industrial environments?
A: The unit is specified for operation in environments with 20-85% RH humidity without condensation. For applications in harsh environments with significant dust ingress or high moisture levels, protective enclosures or specialized industrial-grade lighting solutions may be necessary. Our sourcing experts can help assess your environmental conditions and recommend appropriate solutions.
Q: What are the implications of using a non-specified power supply with the MV-LBSS-27-27-W?
A: Using a power supply that does not meet the specified voltage and current requirements can lead to reduced performance, premature LED degradation, or potential damage to the unit. It is crucial to use a stable, low-voltage DC power supply consistent with the device's power specifications, typically provided by machine vision controllers or dedicated power supplies.
Q: How does the MV-LBSS-27-27-W compare to other illumination types like ring lights or bar lights for my application?
A: The MV-LBSS-27-27-W, as a flat panel light, excels at providing uniform, diffused illumination ideal for inspecting flat surfaces, reducing glare and shadows. Ring lights are suitable for coaxial or diffuse illumination, while bar lights are effective for edge detection or illuminating longer objects. The best choice depends on your specific object, inspection task, and desired imaging outcome. Our technical support can provide a comparative analysis based on your detailed application requirements.
Q: What are the options for integrating the MV-LBSS-27-27-W into existing control systems?
A: The MV-LBSS-27-27-W features an SMR-03V-B connector, which is a standard interface for many industrial vision systems. It supports continuous and strobe working modes, allowing for flexible control via a strobe controller or constant current source. Compatible controllers are available to ensure precise triggering and dimming control.
Q: Is it possible to obtain custom wavelengths or color temperatures for the MV-LBSS-27-27-W for specialized applications?
A: The standard model is offered in high-intensity white (6000-7000K) for broad compatibility with monochrome sensors. For applications requiring specific wavelengths or color temperatures, custom solutions can be explored. Please contact our technical sales team to discuss your unique requirements.
Q: What is the typical lead time for ordering a large quantity of MV-LBSS-27-27-W units for a production line?
A: Lead times for bulk orders are dynamic and depend on current inventory levels and production schedules. Authorized regional distributors can provide accurate lead time estimates and manage phased deliveries. To check real-time stock allocation or request an official quote, contact Beijing Zhongping Technology Co., Ltd. directly.
