The SCHNEEBERGER BM W 20-B-G2-V2 linear module delivers heavy-duty precision with a 20mm rigid profile and ball screw drive.Engineered for 500N dynamic loads
and±0.005mm repeatability,it excels in CNC automation and robotic machining.With hardened steel guides and IP54 protection,it withstands metal chips/coolants in harsh
industrial environments.
Product Parameters
Parameter Value
Module Width 20 mm
Drive Type Ball Screw(C5 grade)
Max.Stroke Length 1500 mm
Max.Speed 1.2 m/s
Repeatability±0.005 mm
Dynamic Load Capacity 500 N
Static Load Capacity 1500 N
Screw Lead 5/10/20 mm
Stiffness 200 N/μm
Protection Class IP54
Key Features&Advantages
Industrial-Grade Rigidity
Dual preloaded guideways resist 15 Nm moment loads.Ideal for milling attachment positioning.
Zero-Backlash Ball Screw
C5-grade ground screws maintain accuracy after 10,000+km travel.Preload adjustable via spacer kits.
Integrated Safety
STO(Safe Torque Off)input enables Category 3 PLd safety compliance for collaborative cells.
Thermal Stability
Aluminum-steel composite design minimizes thermal growth(0.003mm/°C).Optional cooling jackets available.
Application Scenarios
CNC Tool Changers:24/7 spindle interface positioning
Press Automation:Die handling in stamping lines
Coordinate Measuring Machines:Probe head precision alignment
Installation&Usage Notes
Mounting Protocol
Grind mounting surface to<5μm flatness per 100mm
Torque M5 bolts to 4.5 Nm in cross pattern
Laser-align screw parallelism within 0.02mm/m
Maintenance Requirements
Relubricate screw every 300 hours(SCHNEEBERGER EP2 grease)
Inspect wipers quarterly for particle ingress
Monitor preload via torque variation(<10%baseline)
Critical Warnings
⚠️Never lift by carriage–use profile lifting lugs
⚠️Avoid condensation:Preheat to ambient+5°C in cold starts
⚠️ESD-sensitive:Ground via dedicated GND terminal
1.How to optimize ball screw life in high-load applications?
Keep axial loads below 80%dynamic capacity.Maintain lubrication film thickness>0.1μm.Use SCHNEEBERGER's SRA software for load distribution analysis.Schedule vibration
analysis every 2000 hours.
2.Can I use this module in vertical machining centers?
Yes,Z-axis mounting supports 35kg payloads.Always incorporate counterbalance systems.Verify motor brake torque exceeds 1.5x payload moment.Seal screw ends against
coolant ingress.
3.What controllers achieve±0.005mm accuracy?
Pair with EtherCAT drives(e.g.,Beckhoff AX8000).Implement full-closed loop with 0.1μm linear scales.Compensate thermal drift via integrated sensors.
4.How to handle chip contamination in machining cells?
Install optional steel scrapers(P/N:SCR-20B).Route purge air through profile channels.Orient module≥15°from horizontal to facilitate debris fall.
5.Is re-ball screw preload adjustment possible?
Yes,via spacer shim kits(PK-20B).Requires 50Nm torque wrench and dial indicator.Target 5μm axial play after 100km run-in.
6.What motor specs match 20-B-G2-V2 performance?
Select 400W+servos with≥24-bit encoders.Maintain 3:1 inertia ratio.Use SCHNEEBERGER's MA-20B adapter for direct coupling.
7.How to recover accuracy after crash events?
First,check screw straightness with 0.01mm/m tolerance gauge.Replace carriage if impact exceeds 300N.Recalibrate home position via mechanical stopper.
8.Does it support multi-axis gantry configurations?
Yes,with coplanar alignment plates(CP-20).Synchronize via cross-coupled control.Max.sync error:0.02mm over 1m travel.
9.What lubrication intervals apply in food processing?
NSF H1 greases require 150-hour cycles.Clean residue with food-grade solvents.Inspect weekly for microbial growth in humid environments.
10.How to integrate STO safety functionality?
Wire dual-channel signals to pins 12/13.Test weekly via simulated power loss.Validation requires PLd-certified safety relays.
