The SCHNEEBERGER BM W 15-A-G2-V2 precision linear module features a compact 15mm width profile and integrated ball screw drive.Designed for high-accuracy applications,i
t delivers±0.01mm repeatability and supports speeds up to 1.5 m/s.Ideal for laboratory automation and semiconductor handling,this module minimizes space while maximizing
rigidity.Its corrosion-resistant aluminum construction ensures longevity in cleanroom environments.
Product Parameters
Parameter Value
Module Width 15 mm
Drive Type Ball Screw
Max.Stroke Length 1000 mm
Max.Speed 1.5 m/s
Repeatability±0.01 mm
Load Capacity 150 N(dynamic)
Protection Class IP54
Mounting Options Horizontal/Vertical
Key Features&Advantages
Space Optimization:15mm width saves 30%footprint vs standard units.
Ball Screw Precision:Near-zero backlash for micrometric positioning.
Rigid Guide System:Dual-row bearings handle moment loads up to 3 Nm.
Modular Design:Compatible with SCHNEEBERGER motor adapters for servo/stepper integration.
Applications
Optical sensor alignment in metrology equipment
PCB component placement machines
Micro-dispensing systems in medical devices
Installation Notes
Align mounting base within 0.05mm/m flatness.
Use SCHNEEBERGER lubricant(P/N:LUB-15A)quarterly.
Avoid lateral impacts during handling to protect recirculating ball bearings.
1.What’s the lifespan of BM W 15-A-G2-V2 ball screws?
Ball screws last 15,000+hours under 80%max load.Regular lubrication extends service intervals.Avoid contamination with sealing kits(sold separately).Replace preload nuts
when backlash exceeds 5μm.
2.Can I use this module vertically?
Yes,vertical mounting is certified.Ensure motor torque covers payload+counterbalance.Use mechanical brakes for safety during power loss.Check stiffness ratings for Z-axis
oscillations.
3.How to troubleshoot vibration issues?
First,verify mounting surface flatness(<20μm/m).Balance rotating components using ISO 1940 G2.5 standard.Adjust drive parameters via controller damping settings.
4.Is thermal compensation necessary?
For±0.005mm accuracy over 25°C shifts,add SCHNEEBERGER’s CTE sensor.Most applications under 30°C ambient don’t need it.Monitor motor temperature for drift.
5.What motors are compatible?
Supports NEMA 11/17 steppers and 40-60mm servos.Use adapter plates AM-15A.Ensure motor inertia ratio<5:1 vs load.Custom flanges available for direct drive.
6.Can I daisy-chain multiple modules?
Yes,with end connector kits(EC-15).Synchronize via EtherCAT/CANopen.Calibration shims ensure coplanar alignment.Max cumulative error:0.1mm/m.
7.How to clean for cleanroom use?
Wipe with IPA(isopropyl alcohol).Avoid solvents damaging seals.Replace wipers annually(P/N:WPR-15A).Vacuum purge before ISO Class 5 environments.
8.What’s the maintenance schedule?
Relubricate every 250 km travel or 6 months.Inspect ball tracks for pitting.Torque mounting bolts to 3.5 Nm quarterly.Log runtime via encoder feedback.
9.Does it work with third-party controllers?
Compatible with Siemens,Beckhoff,and B&R PLCs.Use analog±10V or PWM signals.Download motion profiles from SCHNEEBERGER’s configurator software.
10.How to handle overload protection?
Install torque limiters(TL-15 kit).Set controller current thresholds at 120%rated.Emergency stop cuts power via STO input.Monitor via built-in thermal sensors.
