The SCHNEEBERGER BM W 15-C-G2-V2 precision linear actuator integrates a polyurethane belt drive in a 15mm-wide aluminum profile.It delivers rapid motion up to 3m/s with
±0.02mm repeatability,ideal for high-speed pick-and-place robotics.Engineered for packaging and lab automation,this IP54-rated module minimizes maintenance while maximizing
throughput in confined spaces.
Product Parameters
Parameter Value
Module Width 15 mm
Drive Type Belt Drive
Max.Stroke Length 500 mm
Max.Speed 3 m/s
Repeatability±0.02 mm
Dynamic Load Capacity 100 N
Acceleration 50 m/s²
Belt Tension System Tool-free Adjustment
Protection Class IP54
Operating Temperature 0°C to+50°C
Key Features&Advantages
High-Speed Belt Drive
Polyurethane fiberglass belts enable rapid cycling without backlash.Achieve accelerations of 50m/s²for reduced cycle times in assembly lines.
Space-Optimized Design
15mm width saves 40%footprint versus screw-driven alternatives.Dual V-guide rails maintain rigidity during high-speed reversals.
Modular Integration
Pre-drilled NEMA 17/23 motor mounts simplify servo integration.Use SCHNEEBERGER’s end connector kits for multi-axis synchronization.
Low-Maintenance Operation
Self-lubricating bearings and sealed guides withstand dust/chips.Relubrication intervals exceed 5,000 km travel.
Application Scenarios
PCB Component Placement:High-speed positioning for SMD feeders
Pharmaceutical Dispensing:Precise liquid handling in ISO Class 5 cleanrooms
Packaging Robotics:Case erecting and label application at 120 cpm
Installation&Usage Notes
Mounting Requirements
Ensure mounting surface flatness<0.05mm/m
Align drive pulleys within±0.1°parallelism
Pre-tension belts to 150Hz resonant frequency
Operational Best Practices
Limit lateral loads to 80N to prevent belt tooth shear
Monitor belt tension quarterly using SCHNEEBERGER FTA-15 gauge
Avoid abrupt direction changes above 2m/s
Critical Warnings
⚠️Never exceed 300N static load to avoid rail deformation
⚠️Install mechanical stops for emergency overtravel protection
⚠️Use ESD-safe versions(BM W 15-C-G2-V2-ESD)for semiconductor handling
1.What’s the belt lifespan under continuous 3m/s operation?
Expect 1,500+km travel before replacement.Monitor for tooth deformation every 500 hours.High-inertia loads reduce lifespan by 30%.
2.Can I mount this module vertically for Z-axis applications?
Vertical mounting is certified with payloads≤5kg.Always use spring counterbalances for load compensation.Verify motor torque reserves cover gravity loads.
3.How to reduce vibration during high-speed starts/stops?
Tune servo PID settings for critical damping.Add mass dampers to the carriage.Ensure pulley sets are dynamically balanced to G2.5.
4.Is encoder feedback necessary for positioning?
Essential for±0.02mm accuracy.Use incremental 1µm linear scales or motor-mounted encoders.Direct encoder input via M12 connectors.
5.What motors deliver optimal performance?
48V DC servos(≤400W)or NEMA 23 steppers.Match motor inertia to load within 1:5 ratio.Avoid oversizing to prevent belt resonance.
6.How to synchronize multiple BM W 15-C-G2-V2 modules?
Use EtherCAT with SCHNEEBERGER’s MC-4 controller.Mechanical coupling requires alignment shims≤0.03mm tolerance.
7.Can belts be replaced in-field without recalibration?
Yes,via tool-free tensioners.Post-replacement homing is mandatory.Verify tension with 150Hz±5Hz sonic tester.
8.What cleaning methods suit food-grade environments?
Wipe with NSF H1 lubricants.Never use chloride solvents.Monthly inspect seals for starch/powder ingress.
9.How to troubleshoot position drift issues?
Check pulley set screws(torque to 1.8Nm).Verify grounding continuity for encoder signals.Update controller backlash compensation.
10.Does it support collaborative robot safety standards?
Yes,with integrated STO(Safe Torque Off)via pin 8/9.Pair with light curtains for PLd safety.
